The emergence of user-friendly AI agents is creating massive new hardware demand, which in turn is forcing the semiconductor industry into a complex, multi-year transition to High NA EUV lithography and an entirely new 12-inch photomask standard. Austin Lyons and Vik Sekar unpack the physics and economics of ASML's move to High NA, explaining why it necessitates a shift from 6-inch to 6x12-inch masks and what this means for the timelines of TSMC, Intel, and Samsung."This is where you have to get the whole supply chain coordinated around this. And this is why you really ultimately need ASML's biggest customers to stand up and say, 'We're going to buy this.'"— Austin Lyons, ChipstratKey Takeaways:- ASML's High NA EUV (0.55 NA) solves resolution but creates a new problem: anamorphic optics (4x by 8x demagnification) cut the exposure field in half, effectively doubling the cost per wafer.- The industry's fix for High NA's halved output is a new 6x12-inch photomask standard — the 12-inch dimension compensates for the 8x demagnification, restoring the full 26mm x 33mm reticle size.- This shift to 12-inch masks is a full supply chain problem, which is why TSMC is waiting until 2030 for high-volume manufacturing while the ecosystem matures over the next 5-7 years.- Intel's aggressive first-mover strategy on High NA — with over 1 million wafers processed to date — is a direct reaction to its disastrous delay in adopting the previous generation of EUV.- Nearly 30% of ASML's revenue comes from recurring services (€2.8B of €9B in Q2), giving it a more stable financial profile than a typical equipment manufacturer.- The new wave of AI agents (Astra, Muse, Instinct) is moving from simple instruction-following to proactive partnership, creating hundreds of millions of new users for server CPUs and memory.- Integrating AI agents into ubiquitous text platforms like WhatsApp is key for mass adoption, as it solves the 'blank text box problem' for non-technical users who can simply text a request.Chapters:0:00 Episode Opening2:23 The Rise of AI Agents6:00 Instinct: The Autonomous Agent10:50 Productizing AI for Mass Adoption14:03 From AI Agents to ASML24:29 The Photomask Stitching Problem31:49 High NA's Anamorphic Optics Tradeoff36:39 The Cost of a Halved Reticle37:26 The 6x12-Inch Mask Solution39:08 A Full Supply Chain Problem41:17 TSMC, Samsung & Intel Timelines48:24 Intel's EUV History LessonFollow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskrFollow Semi Doped:Get more of Austin and Vik daily, free: https://daily.semidoped.com/

Austin and Vik react to OpenAI's Jalapeño announcement at Hot Chips. Plus extra spicy questions like should OpenAI sell it, how much of this was AI-written RTL, and where is Anthropic's chip?Key Takeaways:- The chip's core design philosophy is "dark silicon is cheaper than idle accelerators" — using one balanced chip and power-gating unused blocks is more efficient than a two-chip (e.g. GPU + LPU) solution.- The unprecedented nine-month RTL-to-tapeout cycle was enabled by AI for EDA tools, serving as a wake-up call that small, expert teams can now develop Rubin-class chips in under a year.- Jalapeño's key innovation is a NUMA-style architecture that gives each accelerator a local HBM slice, solving the memory contention that throttles performance in unified memory systems.- OpenAI chose Broadcom's ESUN for its scale-up network to connect 128 chips in the rack at 600 GB/s and up to 2,048 chips across 16 racks at 200G --- all scale up!- The design's "regret factor" principle justifies generality — the opportunity cost of being unable to support a future model is far higher than the marginal cost of adding hardware flexibility upfront.Chapters:0:00 Hot Chips Reaction2:32 Designing for User Experience11:16 A Generalized Inference Chip14:18 The Foundry-IDM Analogy18:42 The 'Regret Factor'21:02 The 9-Month Design Cycle23:45 Challenging the Two-Chip Solution35:08 Solving HBM Underutilization36:46 The NUMA Architecture Solution39:28 System-Level ESUN Networking42:06 Dark Silicon vs. Idle Accelerators49:08 A Wake-Up Call for the Industry52:59 Where's Anthropic's Chip?Follow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskrFollow Semi Doped:Get more of Austin and Vik daily, free: https://daily.semidoped.com/

The rise of user-friendly agentic AI platforms will create a massive new demand category for dedicated, high-core-count "agentic CPUs" to execute tasks in parallel, fundamentally reshaping the server CPU market beyond just feeding GPUs.Key Takeaways:- The 'Mac Mini Craze' wasn't about having a GPU on your desk — it was also about security, as users needed a sandboxed machine to run untrusted agent code like OpenClaw, a problem cloud VMs solve too.- In AI servers, the GPU is the 'genius' doing the thinking, while the host CPU is the 'assistant' whose primary job is keeping the GPU fed, requiring high single-core performance.- Agentic tasks create a 'spillover' of parallel work that overwhelms the host CPU, creating a new demand category for dedicated, high-core-count 'agentic CPUs' in separate racks.- The procurement decision for agentic CPUs becomes about cost-per-core, or 'cost per employee' — balancing core count (like AMD's 256-core chips) against single-core speed.- Intel's P-rack (Performance) and E-rack (Efficiency) offerings are a direct response to this need for heterogeneous CPU solutions tailored to different agentic workloads.- The mass adoption of agentic AI could create demand for a billion new CPU cores in the cloud, driven by the convenience of 'easy button' platforms over self-hosting.- A key bottleneck to this heterogeneous future is the orchestration software needed to schedule jobs across different CPUs and accelerators from multiple vendors.Chapters:0:00 Introducing Grok bot3:45 Grok bot's Cloud VM Architecture6:28 The 'Mac Mini Craze' Explained14:38 Three CPU Deployment Models16:02 GPU as Genius, CPU as Assistant21:36 The Limits of the Host CPU25:20 The 'Office Building' Analogy29:09 Cost-Per-Core is the Metric31:20 Intel's P-rack and E-rack37:32 The Orchestration Bottleneck40:19 Where Grok bot's VM Lives44:22 The Unanswered QuestionFollow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskrFollow Semi Doped:Get more of Austin and Vik daily, free: https://daily.semidoped.com/

Tensordyne co-founder and CPO R K Anand joins Austin to discuss the company's strategy for disrupting AI inference. RK explains how Tensordyne combines power-efficient logarithmic math with a battle-hardened networking fabric from partner HPE Juniper. The result is a high-density, air-cooled system designed to efficiently run massive Mixture-of-Experts models in existing data centers.Key Takeaways:- The core innovation isn't just log math, it's the patented method for accumulation. This turns expensive multiplications into cheap additions, freeing die space for a massive on-chip SRAM cache.- Networking is a partnership, not a project. Tensordyne leverages HPE Juniper's 7th-gen router fabric, skipping development cycles to get a 1-2 microsecond latency solution ideal for random MoE traffic.- The power and density claims are radical. By combining log math silicon with an air-cooled fabric, Tensordyne packs 72 chips into a 13U chassis at just 30 kW — a quarter of the space and power of an NVL72.- One go-to-market advantage is air cooling. The 30 kW, 19-inch rack system can be deployed in existing 'brownfield' enterprise and telco data centers that cannot support liquid cooling.- Partnerships de-risk the aggressive timeline. Broadcom provides access to TSMC 3nm and HBM, while strategic investor HPE Juniper provides the carrier-grade fabric with 'five nines' reliability.Chapters:0:00 Introducing Tensordyne5:32 The Juniper vs. Cisco Playbook11:29 Origin Story: Automotive Power Constraints15:37 The Secret Sauce of Log Math18:02 Pivoting to the Data Center22:08 Leveraging a Router Backplane for AI27:22 Why Router Fabrics Suit MoE Models34:12 The Three Phases of Inference Hardware37:40 How One Chip Handles Pre-fill & Decode40:34 The 'Too Good to Be True' System Specs43:31 Go-to-Market: The Air-Cooled Advantage48:21 De-risking with Strategic Partnerships52:37 Solving the Software Problem with AIFollow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskrFollow Semi Doped:Get more of Austin and Vik daily, free: https://daily.semidoped.com/- The software moat is eroding. Tensordyne argues that modern agentic AI workflows can now automate the generation of optimized software kernels, solving the classic adoption problem for new hardware.

Austin Lyons and Vik Sekar break down three stories that hit semis last week. They analyze a proposed US ban on Chinese optical transceivers that threatens to cut off 50% of the global supply, the market's reaction to AMD's surprise $800M CapEx spend despite strong earnings, and how a new company called Volta Infrastructure landed a $10B compute deal with Anthropic by pioneering a new financial model for AI.Key Takeaways:- The proposed ban on Chinese optical transceivers is based on a flawed security rationale—the components are simple signal converters, not a meaningful vector for malware.- A ban would be self-defeating, as it would cut off the ~50% of global transceiver supply assembled in China, creating the very data center disruption it claims to prevent.- AMD's successful pivot to a data-center-first company (58% of revenue) is being scrutinized for its high CapEx—$800M vs an expected $200-300M—revealing the hidden costs of securing supply.- Nvidia's use of on-chip SRAM for inference's decode phase highlights a strategic gap for AMD, which lacks a compelling SRAM-based solution to compete on disaggregated workloads.- Volta Infrastructure's $10B deal with Anthropic is an innovation in finance, not tech; it applies low-cost 'infrastructure debt' to AI compute by framing clusters as predictable 'token factories'.- The Volta deal was necessary because all existing CSP capacity is allocated; it acts as a 'clean balance sheet' SPV to secure low-cost debt for Anthropic's new, dedicated Nvidia capacity.Chapters:0:00 Intro: News Take Format0:40 The China Optical Ban4:02 A Flawed Security Rationale11:30 Market & Supply Chain Impact15:07 Investment Paralysis15:52 AMD's Earnings Scrutiny24:46 AMD's Missing SRAM Strategy25:33 Volta's $10B Anthropic Deal28:55 Volta's 'Toll Road' Model32:19 Why the Volta Deal Was Necessary33:38 The 'One Customer' Counterpoint34:27 Wrap: Tech & Financial InnovationFollow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskrFollow Semi Doped:Get more of Austin and Vik daily, free: https://daily.semidoped.com/

The physical limits of copper are forcing a shift to optical interconnects in AI data centers. Austin sits down with GlobalFoundries' Thomas Barber to unpack why GF thinks it can lead that transition twice over: once with its long-running silicon photonics platform, and again with the specialty Silicon Germanium process the industry needs to drive it."The enemy to me right now is copper. I'm trying to beat copper, right? If TSMC wins and we win, that's great because we're both displacing copper. And until all the copper is gone, there's plenty of market to go around."— Thomas Barber, GlobalFoundriesKey Takeaways:- Copper's usable range halves every time the data rate doubles, and 200 Gbps/lane inside a rack-scale AI cluster is already past the point copper can handle.- CPO's real win isn't speed, it's power: saving 20-25 pJ/bit frees part of a data center's fixed 50-100 MW budget to go toward compute instead of moving bits.- GlobalFoundries leads photonics revenue for an unglamorous reason: it moved to 300mm wafers early, which yields 2.25x more die per wafer than the 200mm lines rivals still run.- CPO can end up more reliable than the pluggables it's replacing, not less, because it deletes the physical plug connector, and dust at that connector is the leading cause of field failures.- The OCI MSA picks NRZ over faster PAM4, deliberately going wide and slow, because NRZ's native bit error rate is a million times lower, which simplifies the receiver and cuts power.- GlobalFoundries stacks two specialty processes into one edge: micro-mirror couplers on the photonic side, and Silicon Germanium transistors hitting 350-400 GHz on the electrical side driving them.- The real competitor for silicon photonics isn't another foundry, it's copper itself — and that market is big enough that GlobalFoundries and TSMC can both win without taking share from each other.Chapters:0:00 GlobalFoundries in Photonics1:21 GF's Photonics Strategy3:02 GF's Market Leadership5:06 300mm Wafer Advantage6:55 Copper's Range Limits9:18 Pluggable to CPO13:48 CPO Reliability19:22 OCI MSA Explained26:20 GF's Scale Platform29:04 Micro Mirror Technology31:32 Photonics vs. Copper38:25 Silicon Germanium AdvantageFollow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskrFollow Semi Doped:Get more of Austin and Vik daily, free: https://daily.semidoped.com/

A retimer is a small, unglamorous chip. Astera turned it into a high-margin franchise. Austin and Vik cover why copper gives up at PCIe speeds, what a retimer does that a redriver can't, and how one H100 socket became a moat. Then Scorpio: can Astera take switch share from Broadcom?Key Takeaways:- 30cm of PCB trace at Gen 5's 32 GT/s and the signal is gone. Signal integrity is an inside-the-server problem, not just a rack-to-rack one.- Gen 6 swaps NRZ for PAM4. Four voltage levels instead of two — a third the eye height, ~9.5 dB of SNR gone.- A redriver amplifies, noise included. A retimer recovers the clock and data, rebuilds the signal, and resets the jitter budget.- Astera won H100 by shipping PCIe 5 retimers at volume first, then bundling COSMOS on top. The chip became a fleet telemetry sensor.- Sticky socket: H100 carried straight into an Aries 6 design-in on Blackwell.- Scorpio moves up the stack. Same signal conditioning IP, higher ASP, pointed at Broadcom's PCIe switch business.- Astera granted Amazon a warrant — 3.26M shares at $142.82, vesting against up to $6.5B of purchases through 2033. Equity flowing to the customer, and it sizes the Scorpio P-Series commitment behind Trainium 2 and 3.Chapters:0:00 The Astera Labs Franchise3:32 The PCIe Copper Problem6:53 Signal Smearing and Jitter11:52 Eye Diagrams Explained14:59 Equalization: Fixing the Signal23:52 Redriver vs. Retimer29:30 How Astera Won Nvidia35:22 The Blackwell Scare38:50 Scorpio: Moving into Switches42:52 The UALink vs. Ethernet Battle45:58 Taurus and Leo Product LinesFollow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskrFollow Semi Doped:Get more of Austin and Vik daily, free: https://daily.semidoped.com/

Austin Lyons and Vik Sekar break down the market's recent volatility. They discuss the rising fear around hyperscaler debt, visible in credit default swap (CDS) premiums, and the counter-argument that GPU ROI is actually understated. They then analyze the paradox of SK Hynix's massive stock drop despite record growth, and explain why China's new DUV lithography tool makes 3D chip stacking essential to their strategy.Key Takeaways:*  Hyperscaler debt fears are quantified by rising credit default swap (CDS) premiums, signaling investor nervousness that the AI CapEx firehose is shifting from cash flow to riskier debt.* The counter-take on debt is that hyperscalers are under-earning on GPU assets — as long-term contracts re-price to spot rates 2x higher, the hardware's ROI will justify the financing.* SK Hynix's 20% stock drop despite 257% YoY revenue growth shows a market priced for perfection, where a small miss against consensus triggers a panic disconnected from fundamentals.* The memory market paradox: commodity DRAM is currently more profitable than HBM because HBM's production is 3x less bit-efficient per wafer, consuming scarce supply while DRAM spot prices soar.* China's reported immersion DUV breakthrough is equivalent to ASML's late 2000s-era technology, a step toward self-sufficiency but not a leap to the leading edge.Chapters:0:00 The Market Is Freaking Out0:21 Hyperscaler Debt and Credit Default Swaps3:56 The Counter-Take: Under-Earning on GPUs6:18 SK Hynix: Record Growth, Market Carnage8:10 The HBM vs. DRAM Profitability Paradox10:35 Leverage, Retail, and Panic Selling12:05 China's Immersion DUV Breakthrough13:28 The Limits of DUV: 7nm and Multi-Patterning14:14 Logic Folding and 3D Stacking16:12 A Long Journey to Self-Sufficiency17:05 Surviving Semiconductor CyclicalityFollow Semi Doped:Get more of Austin and Vik daily, free: https://daily.semidoped.com/Follow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskr

Vik Sekar and Austin Lyons tackle the biggest bottleneck in inference: moving data. They break down the three tiers of datacenter networking — scale up, scale out, scale across — and the core engineering trade-off at each layer: copper vs. optics. Topics include Nvidia's extreme measures to keep scale-up fabric electrical (a 78-layer mid-plane PCB), why Co-Packaged Optics is the "holy grail" everyone wants and no one can ship, and the serviceability problem standing in its way.Key Takeaways:A single 72-GPU scale-up rack needs 5,000+ cables spanning ~2 km — at that density, the power and cost of every connection becomes a system-level constraint, not an implementation detail.The scale-up rule is "copper when you can, optics when you must": each pluggable optical module adds ~30W, and with thousands of links in the fabric, that penalty compounds fast.Nvidia is pushing copper past its usual limits with a 78-layer mid-plane PCB — 3x+ the layer count of a typical complex board — specifically to avoid paying the optics power tax in its scale-up fabric.Scale-up isn't just a training problem. Frontier MoE models need 72-GPU domains to hit memory bandwidth targets, which pulls high-performance interconnect into the inference conversation.Scale-up has the highest connection density of the three tiers, making it the largest TAM and the sharpest three-way fight between NVLink, UA-Link, and Ethernet.Co-Packaged Optics could cut interconnect power by two-thirds — but a single failed laser could brick an entire multi-thousand-dollar GPU package, and that serviceability risk is what's keeping it on the roadmap instead of in racks.Chapters: 0:00 The Biggest Problem in Computing 7:14 The Three Tiers of Networking 13:49 Scale Up: Copper vs. Optics 17:59 Front-End vs. Back-End Networks 22:12 The Physical Scale of Cabling 28:46 Nvidia's 78-Layer Mid-Plane 33:16 How Optical Transceivers Work 39:16 The Power Penalty of Pluggables 42:09 The Business of Speed Transitions 44:40 The Promise and Peril of CPO 51:45 The Holy Grail of NetworkingFollow Chipstrat: Newsletter: https://www.chipstrat.com X: https://x.com/austinsemisFollow Vik: Newsletter: https://www.viksnewsletter.com/ X: https://x.com/vikramskrFollow Semi Doped: Get more of Austin and Vik daily, free: https://daily.semidoped.com/

Al Yuen, CEO of PicoJool, talks with Austin about using VCSELs for scale-up optical interconnects in AI data centers. Al explains why gallium arsenide (GaAs) supply is unconstrained while indium phosphide (InP) is limited, and how PicoJool can leverage existing supply chains to ship in the millions per month. They cover the roadmap from 1.6T to 12.8T, the trade-offs among 8×200G, 16×100G, and 32×50G, and the push to train the next generation of photonics engineers.The spec that changed is error rate. AI needs error-free links (10⁻¹⁰–10⁻¹² vs Ethernet's old 10⁻⁶) because GPUs act as one system — one error stalls the whole job.Single-mode optics can't hit the volume. Built for ~100K city-to-city links; datacenters need millions/month — a 10–50× gapGaAs vs InP is the whole supply story. VCSELs run on unconstrained GaAs; single-mode on constrained InP. 1M units: 8–10 weeks vs a sold-out 8–18 months.One platform, three flavors to 1.6T: 8×200G "fast and narrow," 16×100G LPO low-power, 32×50G NRZ "slow and wide" — pick on power, cost, and BER.12.8T needs no new tech — just more of the same: 64 channels (4×16 array in a finger-sized connector) × 200G, scaling channels, bi-di wavelengths, and lane speed.Capacity isn't the time consuming part — qualification is. WIN runs ~1,000 wafers/week at ~240K VCSELs each, so 1M units = ~10 wafers. The wait is tier-1 (>6 mo) and tier-2 (~3 mo) quals.Chapters:0:00 Meet Al Yuen and PicoJool2:29 Inventing the active optical cable5:03 Engineering mindset, copper limits8:43 Why VCSELs13:45 Scale-up and bit error rate20:09 Unconstrained vs constrained supply21:53 Indium phosphide bottleneck25:49 VCSEL design and foundry handoff31:59 Product road map, 200G launch34:16 Path to 3.2T and 12.8T40:10 Ordering a million VCSELs45:10 Ramp timing and training new engineersFollow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskrFollow Semi Doped:Get more of Austin and Vik daily, free!Sign up: https://daily.semidoped.com/

Vik welcomes Val Bercovici from Weka to discuss the rapidly evolving landscape of AI memory and storage. Val explains how Weka's architecture leverages high-bandwidth networks to make storage faster than motherboard DRAM. They dive into KV cache optimizations, the future of NAND flash tiers, and the role of CXL in AI inference. The episode concludes with a look at predictive memory offloading and the AI flywheel.Chapters:0:00 Welcome Val Bercovici, Weka1:59 Memory situation and model routing3:50 KV cache offloading to CMX6:10 Network faster than motherboard13:10 Weka as AI memory infrastructure14:45 Inference market is different16:06 Memory hierarchy and KV cache19:40 KV cache optimizations and demand25:20 DeepSeek's cache read pricing34:49 NAND flash tiers: SLC vs QLC43:01 High Bandwidth Flash (HBF)49:59 CXL versus other interconnectsFollow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskrFollow Semi Doped:Get more of Austin and Vik daily, free!Sign up: https://daily.semidoped.com/

Austin and Vik break down the current memory crisis, where AI demand is driving unprecedented profits for memory makers like Micron, while simultaneously causing inflation and price hikes for consumer electronics. They discuss how even premium brands like Apple are struggling to secure supply, leading them to controversial suppliers. The hosts also explore the long-term implications of AI's insatiable memory appetite and its impact on both data center and consumer markets.Chapters:0:00 Memory crisis hits1:20 AI impacting consumers3:00 AI causing inflation6:48 Consumer demand drop?8:49 AI demand inelastic10:56 Long-term memory outlook11:02 GoPro's memory woes12:24 Apple's pricing power18:20 Apple seeks CXMT DRAM21:38 Shrinkflation for phones23:16 Korea's memory investment26:10 Micron's killing profits33:00 Why AI needs so much DRAM40:27 Future of AI training44:34 Cost-optimizing inferenceFollow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskrFollow Semi Doped:Get more of Austin and Vik daily, free!Sign up: https://www.semidoped.com/

Qualcomm flew Austin to New York for its investor day, where the communications company laid out a plan to make data center, automotive, and IoT two-thirds of its business by FY29. Austin was in the room and asked Cristiano Amon a question on the record. Vik watched the whole thing on YouTube. Together they break down what actually changed.The technical centerpiece is High Bandwidth Compute (HBC): stacking LPDDR on top of logic to expose the whole face of the chip for interconnects, claiming up to 100x more lanes and a path around the HBM bandwidth bottleneck. Austin and Vik dig into what's really under that memory, why "no advanced packaging needed" just moves the hard problem somewhere worse, and how it compares to d-Matrix. And as Austin put it: don't let anyone tell you HBM is dead. MOAR memory.Then the roadmap: the AI200/250/300 accelerators, the C1000 server CPU (5 GHz, 250+ cores, Meta as a customer), the Alphawave and Modular acquisitions, and Chris Lattner's Mojo.The most interesting takeaway might not be the data center at all. Qualcomm's edge play — AI-defined vehicles, cars as token generators, and a $1T robotics opportunity by 2040 — could be where High Bandwidth Compute matters most. Chapters: 0:00 Communications? That's just the start 4:08 Inside Qualcomm's investor day 9:16 Can Qualcomm build a data center business? 13:09 Disaggregated inference opens the door 17:57 High Bandwidth Compute: memory on the XPU 30:29 "No advanced packaging" just moves the problem 36:20 The roadmap, Alphawave, and Modular 46:00 The C1000 CPU and the agentic shortage 50:40 Cars as token generators, the $1T robotics bet 57:32 The memory market: MOARFollow Semi Doped: Get more of Austin and Vik daily, free! Sign up: https://www.semidoped.com/Connect with Vik and Austin: Vik's Paid Substack: https://www.viksnewsletter.com Austin's Paid Substack: https://www.chipstrat.com

New episode: Advanced packaging for AI chips, from wire bonds to TSMC CoWOS and Intel EMIB.Packaging is no longer an afterthought. It is the chip, and Intel's EMIB challenges TSMC's CoWOS.Three CoWOS flavors: silicon, organic RDL, local bridgesEMIB embeds tiny bridges into the substrate, no interposerEMIB-T and EMIB-M add through-silicon vias and power capacitorsGoogle is booking 3M TPUs on EMIB via MediaTek by 2028Package sizes keep climbing: 5.5x reticle today, 40x aheadThis episode is brought to you by SambaNova. Try SambaNova's fast inference today at the SambaNova Dashboard!Connect with Vik and Austin via a daily free newsletter:https://www.semidoped.comVik's Paid Substack: https://www.viksnewsletter.comAustin's Paid Substack: https://www.chipstrat.comChapters: (0:00) "There Is No Chip Without the Packaging" (0:28) Intro and SpaceX IPO Day (5:15) What We're Covering: CoWOS, EMIB, Google (7:40) Simple Packaging: Wire Bonds to Flip Chip (17:07) What Makes Packaging "Advanced" (33:44) CoWOS: Three Flavors Explained (45:30) EMIB: Intel's Embedded Bridge Approach (52:47) EMIB-T and EMIB-M (57:31) CoWOS vs. EMIB Trade-offs (1:02:18) Google's 3M TPU EMIB Order

Austin and Vik discuss their recent experience at Computex, where they met for the first time in person after six months of podcasting together. They share insights about the massive show, the people they connected with, and the exciting developments in AI hardware and interconnect technology. Connect with Vik and Austin via a daily free newsletter:https://www.semidoped.comVik's Paid Substack: https://www.viksnewsletter.comAustin's Paid Substack: https://www.chipstrat.comChapters00:00 Meeting in Person for the First Time03:05 Experiencing Computex: A Massive Show05:17 Connecting with the Audience: Real-Life Encounters06:46 Networking with Industry Leaders10:42 Keynote Highlights: Marvell's Vision15:11 The Future of Interconnects: CPO and Beyond22:54 Exploring Optical Interconnects and Future Technologies25:56 Micro LED Developments and Future Conferences27:34 Power Innovations in Data Centers30:54 Intel's Keynote and New CPU Technologies36:31 Intel Foundry's Advancements and Industry Implications

Huawei dropped a paper claiming 1.4nm-class performance without EUV, and the internet immediately declared ASML dead and US export controls useless. Austin and Vik recorded one day after Memorial Day to unpack what Huawei actually announced at ISCAS 2026 — and why the "EUV killer" headline gets the story backwards.They walk through the tau scaling law (tau is delay, and the idea is to attack it at the system level instead of the transistor), logic folding via hybrid bonding, the Kirin 2026 that doubles transistor count without shrinking, and who can actually manufacture stacked logic. Then the other tau knobs: a unified memory bus and near-packaged optics. Along the way: BESI vs EV Group, die-to-wafer vs wafer-to-wafer bonding, and why hybrid bonding isn't export-controlled the way EUV is.The takeaway is the opposite of the headline. Tau scaling is rational engineering under constraint, it's bullish for ASML (two DUV wafers per product, not fewer), and the moment EUV-enabled fabs stack their own advanced-node wafers, the gap widens instead of narrowing. Bullish advanced packaging, bullish EDA and multiphysics.Chapters:0:00 The "EUV killer" paper that broke the internet2:28 What Huawei actually announced at ISCAS4:00 Tau scaling: optimize delay, not transistors8:58 The equation and the 10x AI claim11:05 Logic folding: stacking logic on logic17:24 Who builds it, and can hybrid bonding be banned?24:16 Why this is bullish for ASML29:49 The other tau knobs: memory and optics35:18 Takeaways: packaging, EDA, multiphysicsFollow Semi Doped:Get more of Austin and Vik daily, free!Sign up: https://www.semidoped.com/Follow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstratFollow Vik:Newsletter: https://www.viksnewsletter.comX: https://x.com/vikramskr

Spend one hour here and you've caught up on the entire arc of semiconductor lithography. Austin and Vik run a masterclass on the technology that decides who gets to make leading-edge chips, and why so few companies can afford to.The thread is economics. An EUV machine runs about $400 million, a new fab needs roughly 15 of them, and the total bill clears $20-30 billion before a single wafer ships. Austin and Vik trace the whole story: Rock's Law and the cost of a fab, what it actually takes to build one, the evolution from 193nm DUV through multi-patterning to 13.5nm EUV, how ASML generates EUV light by exploding falling tin droplets, and the move to high NA and its mirrors. Along the way, the fun history — i-line, krypton fluoride, immersion lithography, and the engineer who started it all by flipping a microscope upside down.Then the part that matters most: where lithography goes next. Two startups, xLight and Substrate, are attacking the cost problem from first principles. xLight wants to decouple the light source from the scanner with a free-electron laser and sell photons as a service. Substrate wants to skip EUV entirely and revive X-ray lithography. If either works, the economics of who can build a fab change completely.Chapters: 0:00 The 13F panic, and today's topic 2:23 Why the real story is economics, not physics 6:18 Austin in the clean room: graphene and bunny suits 10:06 Rock's Law and the $20 billion fab 18:08 DUV, the Sharpie, and a history of light 24:58 Multi-patterning, explained with a football field 34:45 How EUV makes 13.5nm light from tin droplets 41:14 High NA, anamorphic optics, and the half-field tax 46:45 The startups rethinking lithography: xLight and SubstrateRelevant reading: Chipstrat — The economics of lithography: https://www.chipstrat.com/p/lithography-economics Chipstrat — xLight and photons as a service: https://www.chipstrat.com/p/photons-as-a-service Chipstrat — Substrate and X-ray lithography: https://www.chipstrat.com/p/substrate Vik's Newsletter — the viability of X-ray lithography: https://www.viksnewsletter.com/p/an-in-depth-look-at-the-viability Fred Chen — LELE multipatterning and EUV stochastics (Substack): https://frederickchen.substack.com/p/can-lele-multipatterning-help-against Chip War, Chris Miller Focus, Marc Hijink (the ASML book): https://www.amazon.com/Focus-Inside-struggle-complex-machine-ebook/dp/B0CW1FLCD4Follow Chipstrat: Newsletter: https://www.chipstrat.com X: https://x.com/chipstratFollow Vik: Newsletter: https://www.viksnewsletter.com/ X: https://x.com/vikramskrFollow Semi Doped: Get more of Austin and Vik daily, free! Sign up: https://www.semidoped.com/

Cerebras IPO is the only thing to talk about this week. 🔥IPO prices at $185/share. Pops nearly 70% right after. The first wafer-scale chip company to make it public — after a 40-year curse killed every prior attempt.A water-cooler-style convo on what Cerebras actually builds, why a 23 kW wafer is a power and cooling nightmare, why 44 GB of SRAM is both the magic and the wall for LLM inference, and the cursed Trilogy Systems saga that Gene Amdahl tried — and failed — to pull off in 1983.Why does Cerebras leave the whole wafer intact instead of dicing it? How do they route around defects to harvest ~900K working cores out of ~1M? Why is power delivery vertical, and why does the wafer literally expand a tenth of a millimeter when it heats up? What does the OpenAI deal actually buy — wafers, or tokens? And why does that distinction matter?Chapters: 0:00 Cold open: 23 kW per wafer 0:15 Cerebras IPO day at $185 2:39 What's a wafer-scale engine 10:30 Power, cooling, and thermal expansion 18:12 The 44 GB wall 26:35 The Trilogy Systems curse 32:11 Supercomputing → training → inference 39:36 The OpenAI deal and the Wild WestRelevant reading: Vik's Substack post on the Cerebras IPO and OpenAI deal: https://www.viksnewsletter.com/Follow Chipstrat: Newsletter: https://www.chipstrat.com X: https://x.com/austinsemisFollow Vik: Newsletter: https://www.viksnewsletter.com/ X: https://x.com/vikramskrFollow Semi Doped: Get more of Austin and Vik daily, free! Sign up: https://www.semidoped.com/

Gimlet Labs runs an inference cloud built on heterogeneous silicon. Their software traces a PyTorch workload, segments it into its component parts, and schedules each piece onto the best-suited hardware — connecting chips from different vendors on a single high-speed fabric.In this interview, Gimlet co-founder Natalie Serrino and former Intel executive Beltir walk through the architecture (graph trace, optimal split points, lowering each segment to TensorRT on NVIDIA and equivalents elsewhere), the three customer segments they sell into (frontier labs, sovereign clouds, AI natives), and a concrete demo: on GPT-OSS 120B at 8K input / 1K output, running the speculative decoder on a d-Matrix Corsair card while NVIDIA B200s handle the verifier shifts the throughput-vs-interactivity Pareto frontier roughly 4× over GPU-only speculative decode.The most surprising takeaway: most Neoclouds gave significant equity to a single silicon vendor in exchange for capacity. Hardware amortization is around 70% of their annual costs, and the equity terms prevent them from diversifying their silicon. So the only software innovation they can ship is disaggregation on top of one vendor's stack — never across vendors. Gimlet's two-track model (deploying orchestration software inside customer data centers, plus running their own Neocloud built on mixed silicon) is the answer to that constraint.Read the full transcript on Chipstrat.Chapters:0:00 Intro and the chips no one's connected before0:33 Inference cloud for agents1:02 From Intel to Gimlet2:14 The case for heterogeneous inference4:03 Disaggregating inference by resource profile6:24 Tracing PyTorch into a schedulable graph8:08 Connecting chips never connected before10:52 CPUs as the agentic workhorse12:01 Tool calls in the same data center as the LLM13:21 Latency vs throughput on a shared fabric14:57 Three customer buckets15:54 Sovereigns: make an API call, not a porting project19:37 "Cracked software is the platform"22:24 Why merchant silicon vendors need partners25:18 Hyperscalers outsourcing CapEx, not just kernels28:49 AI natives: latency budgets, not just price32:06 The d-Matrix partnership33:31 The Pareto frontier chart35:56 Speculative decode on Corsair: 4× shift37:27 4× faster, or 3× more customers?41:22 Why most Neoclouds can't follow this model42:34 Gimlet's two-track business model44:30 CoreWeave vs Together vs Gimlet45:15 Series A and hiringRelevant reading:The Information on Gimlet helping OpenAI optimize for Cerebras: https://www.theinformation.com/newsletters/ai-agenda/startup-helping-openai-optimize-ai-cerebras-chipsSachin Katti and Zain Asgar coauthored research at Stanford: https://arxiv.org/abs/2507.19635Follow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstrat

What's common to optics and power that ruins everything in the era of AI?Resistance.The same physics that drove interconnects to optics is now driving low-voltage power delivery up to 800V. Austin Lyons (Chipstrat) and Vik Sekar (Vik's Newsletter) unpack it using the Kyber rack as an example.At 600kW and 48V, you're pushing 12,500 amps through a single rack. Power loss scales with I². The math doesn't work. The fix is 800V — and the parts come straight from the EV traction inverter ecosystem (SiC, GaN, IGBTs).We cover the full grid-to-GPU power conversion chain (substation, utility room, PSU, intermediate bus converter, VRM), why vertical power delivery is the CPO equivalent for power, and why the power industry is a much wider open problem than optics or HBM. Plus the new topology fight: 800V → 48V (reuse the existing 48V infrastructure) vs 800V → 6V (skip 48V entirely, like TI and Navitas are pushing).We also touch Coherent's six-inch indium phosphide ramp at Järfälla, Sweden, and why margins are the real read-through next quarter.Relevant reading: Vik's Substack post on power: https://www.viksnewsletter.com/p/power-delivery-as-the-next-physics-wall Google TPU 8i / 8t blog (Boardfly deep dive): https://cloud.google.com/blog/products/compute/tpu-8t-and-tpu-8i-technical-deep-diveGet more of Austin and Vik daily, free! Sign up here: https://www.semidoped.com/Follow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/austinsemisFollow Vik:Newsletter: https://www.viksnewsletter.com/X: https://x.com/vikramskrChapters(00:00) Intro(01:41) Memory tax: inflation, not innovation(03:46) Boardfly: 16 hops to 7(05:12) Coherent's six-inch indium phosphide ramp(12:15) Power is the next physics wall(15:08) Why 48V breaks at 600kW: 12,500 amps(23:05) 800V and vertical power delivery: CPO for power(30:34) Grid to GPU: every stage is a different supply chain(39:20) 800V → 48V or skip straight to 6V?

The hyperscaler memory tax quarter.More CapEx? Pssh. We knew flops needed scaling.But $25B at Microsoft alone just to pay higher component prices? A memory tax. That's the news.NAND? Sold out. HBM? Sold out.What we cover:SanDisk revenue +97% sequential.78% gross margin. Guidance above 80% next quarter.Samsung HBM4 first to ship. Demand outstripping supply.DeepSeek v4 goes SSD-centric. KV cache offloads to flash.Microsoft: $25B of 2026 CapEx is just memory pricing.Jassy: memory shortage pushes on-prem to AWS.Qualcomm: mystery custom ASIC. Ships December.New Semi Doped with @vikramskr and @austinsemis.Check out our Substacks- https://www.viksnewsletter.com/ - https://www.chipstrat.com/Chapters:0:00 Intro and Vik goes full-time5:15 Earnings week: the memory tax7:26 Samsung HBM4 and the Gbps race14:42 Is the memory tax worth it?17:37 SanDisk and the SunDisk origin23:22 78% gross margins and 5-year supply lock-ins29:29 DeepSeek v4 and SSD-centric inference38:49 Hyperscaler CapEx and the cloud pull42:49 AI accelerators: TPU, Trainium, MTIA

Google's Cloud Next 2026 keynote? Fire. 🔥The TPU is now two chips instead of one — 8t for training, 8i for inference — but more interestingly, it's two scale-up networking topologies too.Austin Lyons (Chipstrat) and Vik Sekar (Vik's Newsletter) walk through what actually changed, one day after the announcement. OCS? Yes. AECs? Yep. Copper? Yep. Optics? Yep.We cover Virgo (Google's 47 petabit/second scale-out fabric, built entirely on OCS), Boardfly (the new scale-up topology for MoE inference that cuts hop count from 16 to 7), and the 3D torus Google still uses for training.Why is optical circuit switching the substrate of Google's data center? Why do active electrical cables still carry scale-up traffic inside racks? Why did Google split the CPU layer too, with custom ARM Axion head nodes to keep the TPUs fed?Along the way we trace the Dragonfly topology lineage to a 2008 paper by John Kim, Bill Dally, Steve Scott, and Dennis Abts. Abts went on to build Groq's rack-scale interconnect before landing at Nvidia.Chapters: 0:00 Intro 0:21 Two TPUs for two workloads 2:31 HBM, SRAM, and Axion CPUs 7:22 Why networking is the new bottleneck 17:14 Virgo: rebuilding scale-out on optics 25:24 3D torus Rubik's Cube scale-up for training 34:50 Boardfly: scale-up for MoE inference 42:07 Workload-specific everythingFollow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/austinsemisFollow Vik:Newsletter: https://www.viksnewsletter.com/ X: https://x.com/vikramskr

Matt Steiner, VP of Monetization Infrastructure, Ranking & AI Foundations at Meta, walks through how Meta's ad system actually works, and why the infrastructure behind it differs from what you'd build for LLMs.We cover Andromeda (retrieval on a custom NVIDIA Grace Hopper SKU Meta co-designed), Lattice (consolidating N ranking models into one), GEM (Meta's Generative Ads Recommendation foundation model), and the adaptive ranking model, a roughly one-trillion-parameter recommender served at sub-second latency.We get into why recommender workloads aren't embarrassingly parallel like LLMs (the "personalization blob"), what that means for Meta's MTIA custom silicon roadmap, and how LLM-written kernels (KernelEvolve) flipped the economics of running a heterogeneous hardware fleet. Demand for software engineering has actually gone up as the price has come down. Meta now wants ~100x more optimized kernels per chip.Read the full transcript at https://www.chipstrat.com/p/an-interview-with-meta-vp-matt-steinerChapters:0:00 Intro and scale0:39 How Meta's ad system works2:00 Meta Andromeda and the custom NVIDIA SKU3:30 Lattice: consolidating ranking models5:00 GEM, Meta's ads foundation model6:30 Adaptive ranking for power users8:17 The scale: 3B DAUs at sub-second latency9:40 Why longer interaction histories matter10:45 The anniversary gift analogy12:57 A decade of compute evolution15:21 Meta's infra as a CP-SAT problem16:07 Co-designing Grace Hopper with NVIDIA17:47 Matching compute shape to workload18:26 Influencing hardware and software roadmaps20:23 MTIA: why ads aren't LLMs22:07 The personalization blob and I/O ratios26:38 One trillion parameters at sub-second latency28:26 Heterogeneous hardware trade-offs29:30 KernelEvolve: LLMs writing custom kernels33:30 GenAI and recommender systems cross-pollination35:21 The 2-year infrastructure outlook37:00 Why demand for software engineering is rising38:53 How Matt stays on top of it allRelevant reading:KernelEvolve (Meta Engineering): https://engineering.fb.com/2026/04/02/developer-tools/kernelevolve-how-metas-ranking-engineer-agent-optimizes-ai-infrastructure/Follow Chipstrat:Newsletter: https://www.chipstrat.comX: https://x.com/chipstrat

Austin and Vik discuss Credo's acquisition of Dust Photonics, XPO as the new standard for scale-out (maybe instead of CPO?) and some thoughts about Nuvacore entering the CPU scene for agentic AI.Gavin Baker's tweet: https://x.com/GavinSBaker/status/2044410644301046031?s=20Vik's Substack: https://www.viksnewsletter.comAustin's Substack: https://www.chipstrat.comChapters00:00 Introduction to the Semiconductor Landscape02:49 The Rise of Nuvacore and CPU Innovations05:27 The Demand for CPUs in the AI Era07:59 Photonics: The Next Frontier in Semiconductors10:26 Credo's Acquisition of Dust Photonics13:12 Vertical Integration in Semiconductor Companies15:15 The Future of Copper and Optical Technologies20:28 The Evolution of AI Training Models25:28 Innovations in Optical Interconnects31:10 The Future of Data Center Connectivity36:56 Strategic Implications in the Optical Ecosystem

In this episode, Austin and Vik discuss if Intel is finally back with CPU partnerships with Google, and heterogeneous inference with SambaNova, while market cap soars above $300B. Vik tries to get his OpenClaw instance to dream every night.Chapters00:00 Anthropic's New Direction: Chip Development02:30 Navigating Subscription Changes and Token Costs05:25 Exploring Alternative AI Models08:10 The Economics of AI: Rent vs. Buy10:56 Intel's Resurgence and Market Dynamics15:23 Intel's Strategic Partnerships and Market Positioning19:37 The Role of IPUs in Modern Computing25:08 Coexistence of x86 and ARM Architectures29:55 Innovations in Chip Architecture and Future Prospects

Reiner Pope is the co-founder and CEO of MatX, the startup building chips designed from first principles for LLMs. Before MatX, Reiner was on the Google Brain team training LLMs, and his co-founder Mike Gunter was on the TPU team. They left Google one week before ChatGPT was released.A counterintuitive throughput insight from the conversation:“Low latency means small batch sizes. That is just Little’s law. Memory occupancy in HBM is proportional to batch size. So you can actually fit longer contexts than you could if the latency were larger. Low latency is not just a usability win, it improves throughput.”We get into:• The hybrid SRAM + HBM bet, and why pipeline parallelism finally works• Overcoming the CUDA moat• Why frontier labs are willing to bet on an AI ASIC startup• Memory-bandwidth-efficient attention, numerics, and what MatX publishes (and what it does not)• Why 95% of model-side news is noise for chip design• Why sparse MoE drives MatX to “the most interconnect of any announced product”• How MatX uses AI for its own chip design• The biggest challenges aheadChapters:00:00 “We left Google one week before ChatGPT”00:24 Intro: who is MatX01:17 Origin story: leaving Google for LLM chips02:21 GPT-3 and the “too expensive” problem04:25 Why buy hardware that is not a GPU05:52 Overcoming the CUDA moat08:46 Early investors09:35 The name MatX09:59 The chip: matrix multiply + hybrid SRAM/HBM12:11 Why pipeline parallelism finally works14:22 Reading papers and Google going dark15:20 Research agenda: attention and numerics17:06 Five specs and meeting customers where they are19:24 Why frontier labs are the natural first customer20:32 Workloads: training, prefill, decode22:18 Little’s law and the throughput case for low latency24:29 Interconnect and MoE topology26:35 Inside the team: 100 people, full stack28:32 Agentic AI: 95% noise for hardware30:35 KV cache sizing in an agentic world32:11 How MatX uses AI for chip design (Verilog + BlueSpec)34:23 Go to market: proving credibility under NDA35:12 Porting effort for frontier labs36:34 Biggest skepticism: manufacturing at gigawatt scale37:32 Hiring plugAustin Lyons @ Chipstrat: https://www.chipstrat.comVik Sekar @ Vik's Newsletter: https://www.viksnewsletter.com/

Intel Foundry just partnered with Elon Musk’s Terafab. What is Terafab anyway, why vertically integrated fabs make sense but the economics don’t (yet!), and what Intel is doing here (hint: no idea).Then: OpenAI acquires TBPN for an estimated $100-300M. Not sure why, but the more interesting thing is the value of niche audiences when five companies control a trillion dollars in AI capex.And finally, Citrini Research sent an analyst to the Strait of Hormuz with a Pelican case full of spy gear, $15K cash, and Cuban cigars. The most unhinged research trip in Substack history.Austin Lyons — Chipstrat (https://chipstrat.com)                                                              Vik Sekar — Vik's Newsletter (https://www.viksnewsletter.com)Subscribe for weekly episodes on semiconductors, AI, infrastructure, and the business of chips.

In this episode, Austin and Vik analyze NVIDIA's $2 billion investment in Marvell NVLink Fusion, exploring its implications for AI infrastructure, interconnect protocols, and the broader chip ecosystem. They also discuss the current memory market surge, DRAM pricing, and Intel's strategic fab buyback, providing deep insights into industry trends and future directions.On SubstackVik: https://www.viksnewsletter.com/Austin: https://www.chipstrat.com/Chapters00:00 NVIDIA's $2 Billion Investment in Marvell20:11 The Memory Market Crisis20:16 The Future of Memory Pricing and Consumer Impact22:55 The Cycle of Supply and Demand in Memory27:23 AI's Impact on Memory Demand31:46 Long-Term Agreements and Market Stability35:07 Intel's Strategic Fab Buyback40:44 Monopoly Analogy: Intel's Market Strategy

In this episode, Austin and Vik analyze recent developments in GloFo patent lawsuits, the impact of TurboQuant on AI inference, and ARM's strategic move into silicon for agentic AI workloads. Read Vik's substack: https://www.viksnewsletter.comRead Austin's substack: https://www.chipstrat.comChapters00:00 Patent Wars in Semiconductor Industry07:14 Understanding TurboQuant and Its Implications24:42 Innovations in Memory Management28:00 The Rise of ARM AGI CPUs32:56 Agentic AI and CPU Compatibility39:54 Performance Metrics in Agentic AI44:52 ARM's Market Timing and Challenges

Austin and Vik break down a packed week in semiconductors, covering GTC, OFC, and Micron earnings. The conversation kicks off with Jensen Huang's bold claim that engineers should spend $250K/year on AI tokens, and whether companies will buy tokens or token generators (i.e., on-prem hardware like the Dell Pro Max with GB300). They dig into the CapEx vs OpEx tradeoffs, data security concerns, and how sharing GPU resources might end up looking a lot like the old EDA license model.Next up: Micron crushed earnings and appears to be designed into Vera Rubin for HBM4 — despite months of rumors saying otherwise. Austin and Vik unpack the nuance around HBM pin speeds, memory node base dies, and what Micron's massive new fab investments in Taiwan, Singapore, Idaho, and New York mean for the memory cycle.The back half of the episode dives into optical interconnects for AI scale-up. A new industry consortium (OCI-MSA) has formed with Meta, Broadcom, NVIDIA, and OpenAI to standardize optical components. Vik explains why traditional indium phosphide lasers might be overkill for short-reach scale-up, and makes the case for micro LEDs — a "slow but wide" approach that could fill the gap between copper and conventional optics. They also touch on Credo's expanding product portfolio (and the infamous purple-to-orange cable saga), plus Lumentum's new VCSEL work for scale-up.Vik - https://www.viksnewsletter.com/Austin - https://www.chipstrat.com/CHAPTERS0:00 Intro & GTC/OFC Conference Overload2:09 Jensen's $250K Token Budget Per Engineer5:08 On-Prem Inference vs. Cloud Token Spending (Dell Pro Max, CapEx vs OpEx)6:44 Sharing GPU Resources Like EDA Licenses8:16 Data Security & On-Prem Privacy Concerns9:53 Matthew Berman's Fine-Tuned Open Claw Agent10:35 Vik Sets Up Open Claw on a Home Server11:53 Always Be Clauden (ABC) – Managing Agents from Your Phone13:34 Micron Earnings & HBM4 in Vera Rubin16:39 HBM Pin Speeds & the Micron Design-In Debate20:17 Micron's New Fab Investments & Memory Cycle Fears23:49 Why AI Drives a Step Change in Memory Demand26:30 Optical Compute Interconnect MSA (OCI-MSA)29:48 Scale-Up Optics: Do We Need New Technology?30:58 Micro LEDs – The "Slow but Wide" Approach35:45 Micro LEDs vs. Copper vs. Traditional Optics36:55 Credo's Product Spectrum & the Purple Cable Story39:31 VCSELs & Lumentum's 1060nm Scale-Up Play

Vik and Austin unpack the Nvidia GTC keynote with fresh, top-of-mind takes while trying to breakdown key announcements, what matters and what doesn't. They discuss Groq's LPX, optics+copper for scale up, new CPU requirements, CPO for networking, and what agents means for software, and much, much, more.Check out Austin's substack: https://www.chipstrat.comCheck out Vik's substack: https://www.viksnewsletter.comChapters00:00 Introduction and Keynote Context03:18 Keynote Highlights and Gaming Innovations06:18 Generative AI: The Three Eras09:28 Inference: The New Revenue Generator12:21 NVIDIA's Tiered Approach to AI Models15:30 The Grok Chip and Its Role18:35 Vera Rubin System: A Full Data Center21:18 CPU Demand and Performance24:31 Networking Innovations and Future Directions32:32 Innovations in PCB Technology34:06 Scaling GPU Systems36:57 Understanding the STX Rack and AI Storage38:23 The Rosa CPU and Its Significance40:07 Digital Twin Platforms and AI Factories43:53 NVIDIA's New Software Innovations47:09 The Future of Token Budgets in AI54:15 Balancing CapEx and OpEx in AI Deployments

Austin recaps moderating an agentic AI panel at Synopsys Converge, then gives an in-depth technical breakdown of Meta's MTIA custom silicon. Why they're building it, how chiplets let them ship a new chip every 6 months, and how the roadmap is shifting toward gen AI inference. Vik digs into Applied Optoelectronics (AAOI), the vertically integrated Texas laser shop whose stock went from $1.48 to $100+, and whether history is about to rhyme.                     Austin Lyons: https://www.chipstrat.comVik Sekar: https://www.viksnewsletter.com/                                                                                                                                  Topics covered:• Agentic AI in chip design — how it changes roles for junior and senior engineers• Optical circuit switching and what it means for Arista's business model• Meta's ad-serving pipeline: Andromeda, Lattice, and the GEM foundation model• Why custom silicon (MTIA) makes sense at Meta's scale• MTIA chiplet strategy — 4 generations in 2 years• AAOI's vertical integration, Amazon's $4B warrant deal, and the 2017 parallelChapters:0:00 Intro1:26 Synopsys Converge — Agentic AI Panel9:44 Vik's Article: Optical Circuit Switching & Arista14:43 Meta MTIA — A New Chip Every 6 Months21:32 Why Custom Silicon Makes Sense for Meta27:22 MTIA Chiplet Strategy & Roadmap33:56 Gen AI Fits Meta's Business Model36:31 How Meta Ships Chips So Fast40:30 Applied Optoelectronics (AAOI) Deep Dive45:02 Amazon's $4B Warrant Deal48:54 Can AAOI's Lasers Compete with Lumentum?53:16 AAOI's Aggressive Capacity Buildout55:35 History Rhymes: AAOI's 2017 Boom & Bust1:00:55 Wrap-Up#semiconductors #chips #tech #meta #MTIA #AAOI #optics #inference #AI

This week, Austin and Vik break down the optics vs. copper debate that rocked semis this week. Nvidia dropped $4 billion on Lumentum and Coherent, Credo posted a blowout quarter betting on copper, and then Hock Tan shocked everyone claiming 400G per lane works over copper in Broadcom’s labs — potentially pushing CPO out to 2030+. Plus, Vik’s 4D chess conspiracy theory on why Hock Tan is talking up copper when Broadcom is a CPO company.Like, subscribe, and drop your thoughts on the copper vs. optics debate in the comments!Subscribe to our newsletters:* Chipstrat by Austin Lyons — chipstrat.com* Vik’s Semiconductor Newsletter by Vik Sekar  — viksnewsletter.comChapters(00:00) - Newsletter Plugs: Groq LPUs & Broadcom’s Laser Business(03:15) - Dynamo & the Rise of Workload-Specific Hardware(08:04) - Austin’s Broadcom Laser Deep Dive(09:53) - The Week’s Whiplash: Optics Monday, Copper Wednesday(17:50) - Why Nvidia Invested $4B: Geopolitics, Supply & the HBM Playbook(24:15) - CPO Lasers & Optical Circuit Switches(26:16) - Credo Earnings: 200% YoY Growth & the Copper Bull Case(31:09) - Reliability, AECs & Oracle’s GPU Cluster Problem(35:48) - Credo’s Optics Play: Micro-LED Active Cables & the CPO Timing Risk(38:45) - Broadcom Earnings: Hock Tan’s Copper Bombshell(43:34) - Customer-Owned Tooling: Hock Tan Says “Good Luck”(44:25) - Vik’s 4D Chess Theory: Why Hock Tan Talks Up Copper(47:03) - Wrap-Up: It’s Both — The Real Question Is Timing

This week, we move from optics technology to optics companies. We walk the AI optical supply chain from bottom to top. Main debate: Who has a moat? Who is already priced for perfection?  *Not investment advice, do your own due diligence*AXTI - Indium phosphide substrate supplier. Critical bottleneck in the laser stack. Major China export-control risk. Massive stock run vs thin earnings.Tower Semiconductor - Leading silicon photonics foundry. 5x capacity expansion with customer prepayments. Strong process lock-in. Pure-play optics exposure.GlobalFoundries - 300mm monolithic photonics platform + Chips Act support. Optics growing fast but still small piece of overall business.Lumentum - Dominant EML laser supplier. Explosive AI demand. Strong technical moat. Valuation and capex sensitivity are key risks.Coherent - Vertically integrated from substrate to module. 6-inch InP push could lower costs structurally. Execution and margin mix matter.Fabrinet - Optics assembly partner. High NVIDIA exposure. Scales with industry, but dependent on upstream supply.Corning - AI data centers require far more fiber than traditional cloud. $6B Meta deal adds visibility. Timing of scale-up optics is the swing factor.Timestamps00:01 Intro06:59 AXT $AXTI13:38 Tower Semiconductor $TSEM23:58 GlobalFoundries $GFS32:43 Lumentum $LITE39:38 Coherent $COHR47:09 Fabrinet $FN54:07 Corning $GLWAustin's Substack: https://www.chipstrat.com/Vik's Substack: https://www.viksnewsletter.com/

Austin and Vik delve into the evolving landscape of optics and networking, particularly in relation to AI and data centers. The conversation covers various scales of networking, including scale across, scale out, and scale up, while also addressing the demand-supply dynamics in laser manufacturing and the future of optical circuit switches. The episode highlights the technological advancements and market opportunities in the optics sector, emphasizing the significance of these developments for the future of AI.TakeawaysSilicon photonics is becoming crucial for data center connectivity.Optics is essential for overcoming copper's limitations in speed and distance.Scale across technology is vital for connecting data centers.Scale out optics is the standard for connecting GPUs between racks.Co-packaged optics can reduce energy consumption in data centers.The scale up market for optics is emerging as a new opportunity.Indium phosphide wafers are a critical bottleneck in laser manufacturing.Optical circuit switches are gaining traction in data centers.2026 is anticipated to be a pivotal year for optical networking. Chapters00:00 Introduction to AI and CPU Bottlenecks03:00 The Rise of Silicon Photonics06:01 Understanding Optical Networking and Data Centers08:49 Scale Across: Connecting Data Centers11:56 Scale Out: Optimizing Data Center Connectivity14:53 Scale Up: The Future of GPU Connectivity23:32 The Shift from Copper to Optical Connections26:13 Challenges and Reliability of Lasers30:47 Understanding Co-Packaged Optics34:17 Market Dynamics: Demand and Supply of Lasers40:46 Emerging Technologies: Optical Circuit SwitchesCheck out Austin's Substack: https://www.chipstrat.comCheck out Vik's Substack: https://www.viksnewsletter.com

In this episode of the Semi Doped podcast, Austin and Vik delve into the current state of the semiconductor industry, focusing on the memory crisis driven by increasing demand from AI applications. They discuss the implications of rising memory prices, the impact of hyperscaler spending on the market, and the strategic moves of major players like Google, Microsoft, Meta, and Amazon in the AI landscape. TakeawaysMemory prices are skyrocketing, impacting consumer electronics.The memory crisis is affecting the production of lower-end devices.DRAM prices have doubled in a single quarter, creating challenges for manufacturers.Nanya Tech's revenue growth indicates a booming memory market.AI applications are driving unprecedented demand for memory.Hyperscalers are significantly increasing their capital expenditures for AI infrastructure.The integration of AI into advertising is reshaping business models for companies like Google and Meta.Chapters00:00 The State of Memory in Semiconductors03:08 Nvidia's GPU Dilemma and Market Dynamics06:13 The Impact of AI on Memory Demand09:08 NAND Flash and Context Memory Trends11:59 The Future of Memory Supply and Demand15:12 AI Infrastructure and CapEx Spending17:47 Google's Strategic Investments in AI20:58 The Advertising Business Model and AI Integration30:26 Revenue vs. Expenses: A Balancing Act31:08 The Future of TPUs vs. GPUs in Cloud Computing35:31 Microsoft vs. Google: AI Investments and Market Reactions38:22 AI Integration in Enterprises: Microsoft’s Unique Position39:57 The Power of Microsoft’s Reach in AI40:30 GitHub: A Hidden Gem for Microsoft’s AI Strategy43:52 Meta’s AI Strategy: Advertising and Revenue Growth51:18 Amazon’s Massive CapEx: Implications for the Future54:00 Looking Ahead: Predictions for 2027 and BeyondCheck out Austin's substack: https://www.chipstrat.com/Check out Vik's substack: https://www.viksnewsletter.com/

In this episode, Vik and Wayne Nelms discuss the emerging financial exchange for GPU compute, exploring its implications for the AI infrastructure market. They discuss the value of compute, pricing dynamics, hedging strategies, and the future of GPU and memory trading. Wayne shares insights on partnerships, the depreciation of GPUs, and how inference demand may reshape hardware utilization. The conversation highlights the importance of financial products in facilitating data center development and optimizing profitability in the evolving landscape of compute resources.TakeawaysWayne Nelms is the CTO of Ornn, focusing on GPU compute as a commodity.The value of compute is still being defined in the market.Hedging strategies are essential for managing compute costs.The pricing of GPUs varies significantly across providers.Memory trading is becoming a crucial aspect of the compute market.Partnerships can enhance trading platforms and market efficiency.Depreciation of GPUs is not linear and varies by use case.Inference demand may change how GPUs are utilized in the future.Transparency in pricing benefits smaller players in the market.Financial products can facilitate data center development and profitability.Chapters00:00 Introduction to GPU Compute Futures03:13 The Value of Compute in Today's Market05:59 Understanding GPU Pricing Dynamics08:46 Hedging and Futures in Compute11:52 The Role of Memory in AI Infrastructure15:14 Partnerships and Market Expansion17:46 Depreciation and Residual Value of GPUs20:57 Future of Data Centers and Compute Demand24:01 The Impact of Financialization on AI Infrastructure27:04 Looking Ahead: The Future of Compute MarketsKeywordsGPU compute, financial exchange, futures market, data centers, AI infrastructure, pricing strategies, hedging, memory trading, Ornn Follow Wayne Nelms (@wayne_nelmz on X)Check out Ornn's website: https://www.ornnai.com/Check out Vik's Substack: https://www.viksnewsletter.com/Check out Austin's Substack: https://www.chipstrat.com/

Vik and Val Bercovici discuss the evolution of storage solutions in the context of AI, focusing on Weka's innovative approaches to context memory, high bandwidth flash, and the importance of optimizing GPU usage. Val shares insights from his extensive experience in the storage industry, highlighting the challenges and advancements in memory requirements for AI models, the significance of latency, and the future of storage technologies.TakeawaysContext memory is crucial for AI performance.The demand for memory has drastically increased.Latency issues can hinder AI efficiency.High bandwidth flash offers new storage capabilities.Weka's Axon software enhances GPU storage utilization.Token warehouses can significantly reduce costs.Augmented memory grids improve memory access speeds.Networking innovations are essential for AI storage solutions.Understanding memory hierarchies is vital for optimization.The future of storage will involve more advanced technologies.Chapters00:00 Introduction to Weka and AI Storage Solutions05:18 The Evolution of Context Memory in AI09:30 Understanding Memory Hierarchies and Their Impact16:24 Latency Challenges in Modern Storage Solutions21:32 The Role of Networking in AI Storage Efficiency29:42 Dynamic Resource Utilization in AI Networks30:04 Introducing the Context Memory Network31:13 High Bandwidth Flash: A Game Changer32:54 Weka's Neural Mesh and Storage Solutions35:01 Axon: Transforming GPU Storage into Memory39:00 Augmented Memory Grid Explained42:00 Pooling DRAM and CXL Innovations46:02 Token Warehouses and Inference Economics52:10 The Future of Storage InnovationsResourcesManus AI $2B Blog: https://manus.im/blog/Context-Engineering-for-AI-Agents-Lessons-from-Building-ManusAlso listen to this podcast on your favorite platform. https://www.semidoped.fm/Check out Vik's Substack: https://www.viksnewsletter.com/Check out Austin's Substack: https://www.chipstrat.com/

Austin and Vik discuss the emerging trend of AI agents, particularly focusing on Claude Code and OpenClaw, and the resulting hardware implications.Key Takeaways:2026 is expected to be a pivotal year for AI agents.The rise of agentic AI is moving beyond marketing to practical applications.Claude Code is being used for more than just coding; it aids in research and organization.Integrating AI with tools like Google Drive enhances productivity.Security concerns arise with giving AI agents access to personal data.Local computing options for AI can reduce costs and increase control.AI agents can automate repetitive tasks, freeing up human time for creative work.The demand for CPUs is increasing due to the needs of AI agents.AI can help summarize and organize information but may lack deep insights.The future of AI will involve balancing automation with human oversight.Chapters(00:00) Introduction: Why 2026 may be the year of AI agents(01:12) What people mean by agents and the OpenClaw naming chaos(02:41) Agents behaving badly: crypto losses and social posting(03:38) Claude Code as a research tool, not a coding tool(05:54) Terminal-first workflows vs GUI-based agents(07:44) Connecting Claude Code to Gmail, Drive, and Calendar via MCP(09:12) Token waste, authentication friction, and workflow optimization(10:54) Automating newsletter ingestion and research archives(12:33) Giving agents login credentials and security tradeoffs(13:50) Filtering signal from noise with topic constraints(16:36) AI-driven idea generation and its limitations(17:34) When automation effort is not worth it(19:02) Are agents ready for non-technical users?(20:55) Why OpenClaw should not run on your personal laptop(21:33) Safe agent deployment: VPS vs local servers(23:33) The true cost of agents: infrastructure plus inference(24:18) What OpenClaw adds beyond Claude Code(26:53) Agents require managerial thinking and self-awareness(28:18) Local inference vs cloud APIs(30:46) Cost control with OpenRouter and model hierarchies(32:31) Scaling agents forces model and cost optimization(33:00) AI aggregation vs creator analytics(35:58) AI as discovery, not a replacement for reading(38:17) When summaries are enough and when they are not(39:47) Why AI cannot understand what is not said(41:18) Agentic AI is driving unexpected CPU demand(41:49) Intel caught off guard by CPU shortages(44:53) Security, identity, and encryption shift work to CPUs(46:10) Closing thoughts: agents are real, early, and unevenDeploy your secure OpenClaw instance with DigitalOcean:https://www.digitalocean.com/blog/moltbot-on-digitaloceanVisit the podcast website: https://www.semidoped.fmAustin's Substack: https://www.chipstrat.com/Vik's Substack: https://www.viksnewsletter.com/

Maia 100 was a pre-GPT accelerator.Maia 200 is explicitly post-GPT for large multimodal inference.Saurabh Dighe says if Microsoft were chasing peak performance or trying to span training and inference, Maia would look very different. Higher TDPs. Different tradeoffs. Those paths were pruned early to optimize for one thing: inference price-performance. That focus drives the claim of ~30% better performance per dollar versus the latest hardware in Microsoft’s fleet.Intereting topics include:• What “30% better price-performance” actually means• Who Maia 200 is built for• Why Microsoft bet on inference when designing Maia back in 2022/2023• Large SRAM + high-capacity HBM• Massive scale-up, no scale-out• On-die NIC integrationMaia is a portfolio platform: many internal customers, varied inference profiles, one goal. Lower inference cost at planetary scale.Chapters:(00:00) Introduction(01:00) What Maia 200 is and who it’s for(02:45) Why custom silicon isn’t just a margin play(04:45) Inference as an efficient frontier(06:15) Portfolio thinking and heterogeneous infrastructure(09:00) Designing for LLMs and reasoning models(10:45) Why Maia avoids training workloads(12:00) Betting on inference in 2022–2023, before reasoning models(14:40) Hyperscaler advantage in custom silicon(16:00) Capacity allocation and internal customers(17:45) How third-party customers access Maia(18:30) Software, compilers, and time-to-value(22:30) Measuring success and the Maia 300 roadmap(28:30) What “30% better price-performance” actually means(32:00) Scale-up vs scale-out architecture(35:00) Ethernet and custom transport choices(37:30) On-die NIC integration(40:30) Memory hierarchy: SRAM, HBM, and locality(49:00) Long context and KV cache strategy(51:30) Wrap-up

OpenAI's partnership with Cerebras and Nvidia's announcement of context memory storage raises a fundamental question: as agentic AI demands long sessions with massive context windows, can SRAM-based accelerators designed before the LLM era keep up—or will they converge with GPUs?Key Takeaways1. Context is the new bottleneck. As agentic workloads demand long sessions with massive codebases, storing and retrieving KV cache efficiently becomes critical.2. There's no one-size-fits-all. Sachin Khatti's (OpenAI, ex-Intel) signals a shift toward heterogeneous compute—matching specific accelerators to specific workloads.3. Cerebras has 44GB of SRAM per wafer — orders of magnitude more than typical chips — but the question remains: where does the KV cache go for long context?4. Pre-GPT accelerators may converge toward GPUs. If they need to add HBM or external memory for long context, some of their differentiation erodes.5. Post-GPT accelerators (Etched, MatX) are the ones to watch. Designed specifically for transformer inference, they may solve the KV cache problem from first principles.Chapters  - 00:00 — Intro  - 01:20 — What is context memory storage?  - 03:30 — When Claude runs out of context  - 06:00 — Tokens, attention, and the KV cache explained  - 09:07 — The AI memory hierarchy: HBM → DRAM → SSD → network storage  - 12:53 — Nvidia's G1/G2/G3 tiers and the missing G0 (SRAM)  - 14:35 — Bluefield DPUs and GPU Direct Storage  - 15:53 — Token economics: cache hits vs misses  - 20:03 — OpenAI + Cerebras: 750 megawatts for faster Codex  - 21:29 — Why Cerebras built a wafer-scale engine  - 25:07 — 44GB SRAM and running Llama 70B on four wafers  - 25:55 — Sachin Khatti on heterogeneous compute strategy  - 31:43 — The big question: where does Cerebras store KV cache?  - 34:11 — If SRAM offloads to HBM, does it lose its edge?  - 35:40 — Pre-GPT vs Post-GPT accelerators  - 36:51 — Etched raises $500M at $5B valuation  - 38:48 — Wrap up

Innoviz CEO Omer Keilaf believes the LIDAR market is down to its final players—and that Innoviz has already won its seat.In this conversation, we cover the Level 4 gold rush sparked by Waymo, why stalled Level 3 programs are suddenly accelerating, the technical moat that separates L4-grade LIDAR from everything else, how a one-year-old startup won BMW, and why Keilaf thinks his competitors are already out of the race.Omer Keilaf founded Innoviz in 2016. Today it's a publicly traded Tier 1 supplier to BMW, Volkswagen, Daimler Truck, and other global OEMs.Chapters  00:00 Introduction  00:17 Why Start a LIDAR Company in 2016?  01:32 The Personal Story Behind Innoviz  03:12 Transportation Is Still Our Biggest Daily Risk  04:28 The 2012 Spark: Xbox Kinect and 3D Sensing  06:32 From Mobile to Automotive: Finding the Right Platform  07:54 "I Didn't Know What LIDAR Was, But I'd Do It Better"  08:19 How a One-Year-Old Startup Won BMW  10:04 Surviving the First Product  11:23 From Tier 2 to Tier 1: The Volkswagen Win  13:47 Lessons Learned Scaling Through Partners  14:45 The SPAC Decision: A Wake-Up Call from a Competitor  16:42 From 200 LIDAR Companies to a Handful  17:27 NREs: How Tier 1 Status Funds R&D  18:44 Why Automotive-First Is the Right Strategy  19:45 Consolidation Patterns: Cameras, Radars, Airbags  20:31 "The Music Has Stopped"  21:07 Non-Automotive: Underserved Markets  23:51 Working with Secretive OEMs  25:27 The Press Release They Tried to Stop  26:42 CES 2025: 85% of Meetings Were Level 4  27:40 Why Level 3 Programs Are Suddenly Accelerating  28:33 The EV/ADAS Coupling Problem  29:49 Design Is Everything: The Holy Grail Is Behind the Windshield  31:13 The Three-Year RFQ: Grill → Roof → Windshield  32:32 Innoviz3: Small Enough for Behind-the-Windshield  34:40 Innoviz2 for L4, Innoviz3 for Consumer L3  36:38 What's the Real Difference Between L2, L3, and L4 LIDAR?  38:51 The Mud Test: Why L4 Demands 100% Availability  40:50 "We're the Only LIDAR Designed for Level 4"  42:52 Patents and the Maslow Pyramid of Autonomy  44:15 Non-Automotive Markets: Agriculture, Mining, Security  46:15 Closing

Austin and Vik discuss why LiDAR is important for autonomy, how modern systems work, and how the technology has evolved. They compare Time of Flight and FMCW architectures, explain why wavelength choice matters, and walk through the tradeoffs between 905 nm and 1550 nm across eye safety, cost, and performance. The discussion closes with a clear-eyed look at competition, Chinese suppliers, and supply chain risk.Chapters(00:00) Introduction to LiDAR and why it matters(05:40) The case for LiDAR in autonomous vehicles(12:41) Wavelengths, eye safety, and system tradeoffs(15:38) How LiDAR works: Time of Flight vs. FMCW(20:12) Mechanical vs. solid-state LiDAR designs(27:31) Market dynamics, competition, and geopolitics

Episode SummaryAustin and Vik break down NVIDIA’s CES 2026 keynote, focusing on Vera Rubin, DGX Spark and DGX Station, uneducated investor panic, and physical AI.Key TakeawaysDGX Spark brings server-class NVIDIA architecture to the desktop at low power, aimed at developers, enthusiasts, and enterprises experimenting locally.  DGX Station functions more like a mini-AI rack on-prem: Grace Blackwell for inference and development without full racks The historical parallel is mainframes to minicomputers, expanding compute TAM rather than displacing cloud usage.  On-prem AI converts some GPU rental OpEx into CapEx, appealing to CFOs  NVIDIA positioned autonomy as physical AI with vision-language-action models and early Mercedes-Benz deployments in 2026.  Vera Rubin integrates CPU, GPU, DPU, networking, and photonics into a single platform, emphasizing Ethernet for scale-out. (Where was the Infiniband switch?) The new Vera CPU highlights rising CPU importance for agentic workloads through higher core counts, SMT, and large LPDDR capacity.  Rubin GPU’s move to HBM4 and adaptive precision targets inference efficiency gains and lower cost per token.  Context memory storage elevates SSDs and DPUs, enabling massive KV cache offload beyond HBM and DRAM.  Cable-less rack design and warm-water cooling show NVIDIA’s shift from raw performance toward manufacturability and enterprise polish.

Austin and Vik discuss key insights from the IEDM conference. They explore the significance of IEDM for engineers and investors, the networking opportunities it offers, and the latest innovations in silicon photonics, complementary FETs, NAND flash memory, and GaN-on-silicon chiplets. TakeawaysPenta-level NAND flash memory could disrupt the SSD marketGaN-on-Silicon chiplets enhance power efficiencyComplementary FETsOptical scale-up has a power problemThe future of transistors is still bright

Key TopicsWhat Nvidia actually bought from Groq and why it is not a traditional acquisitionWhy the deal triggered claims that GPUs and HBM are obsoleteArchitectural trade-offs between GPUs, TPUs, XPUs, and LPUsSRAM vs HBM. Speed, capacity, cost, and supply chain realitiesGroq LPU fundamentals: VLIW, compiler-scheduled execution, determinism, ultra-low latencyWhy LPUs struggle with large models and where they excel insteadPractical use cases for hyper-low-latency inference:Ad copy personalization at search latency budgetsModel routing and agent orchestrationConversational interfaces and real-time translationRobotics and physical AI at the edgePotential applications in AI-RAN and telecom infrastructureMemory as a design spectrum: SRAM-only, SRAM plus DDR, SRAM plus HBMNvidia’s growing portfolio approach to inference hardware rather than one-size-fits-allCore TakeawaysGPUs are not dead. HBM is not dead.LPUs solve a different problem: deterministic, ultra-low-latency inference for small models.Large frontier models still require HBM-based systems.Nvidia’s move expands its inference portfolio surface area rather than replacing GPUs.The future of AI infrastructure is workload-specific optimization and TCO-driven deployment.
